SECTION 2 - GUIDE RAILS AND CROSS BRACES.
Page 2-1
Rev 1A – Oct. 2003
2.1
Determine which wall will support the guide rails and locate
the center of the wall. Place a mark on the floor at 14 ¾” on
either side if the centerline. This will be the position that you
start setting up your guide rails.
Figure 1. Marking the guiderail location.
MATERIAL LIST PART #
NOTE:
