SECTION 3 - MOTORS AND RUNNING GEAR
Page 3-1
Rev 1B – May 2013
3.1
Hang the working platform on the bottom of the upper
cross brace (FIG. 1) to install the gear reducers and
motor(s).
Figure 1. Hanging the working platform on the upper
cross brace.
NOTE:
MATERIAL LIST PART #
