SECTION 7 – DOOR LOCK OPERATOR CAMS
Page 7-3
Rev 1A – Oct. 2003
GAL Interlocks (Swing Doors)
7.3
Figure 5 shows a typical GAL cam configuration for a shaft up to 59” wide. The extension bracket may or may not be
required.
7.4
Figure 6 shows a typical GAL cam configuration for shaft 60” wide or larger.
Figure 5. GAL cam configuration (carriage up to 59”
wide).
Figure 6. GAL cam configuration (carriage 60” or
wider).
