4.2 Data 4.2 Données techniques4.2 Technische Daten
Technical
Specifications
Spécifications
Technische
Spezifikationen
13
Technical Specifications
S-1500 S-2000 S-3000 S-4000 S-6000 S-3004 S-4004 S-4044 S-6004 S-6044
Output Power
1kHz, 1.0% THD+N
@ 2Ω 2x 880 W 2x 1190 W 2x 1570 W 2x 1950 W 2x 2950 W 4x 700 W 4x 980 W - 4x 1440 W -
@ 4Ω 2x 575 W 2x 790 W 2x 1100 W 2x 1380 W 2x 2025 W 4x 500 W 4x 670 W 4x 975 W 4x 1000 W 4x 1480 W
@ 8Ω 2x 325 W 2x 460 W 2x630 W 2x 810 W 2x 1250 W 4x 300 W 4x 430 W 4x 690 W 4x 620 W 4x 1015 W
Bridge @ 4Ω 1760 W 2380 W 3140 W 3900 W 5900 W 2x 1400 W 2x 1960 W - 2x 2880 W -
Bridge @ 8Ω 1150 W 1580 W 2200 W 2760 W 4050 W 2x 1000 W 2x 1340 W 2x 1950 W 2x 2000 W 2x 2960 W
Pink Noise 12dB C.F.
@ 2Ω 2x 975 W 2x 1360 W 2x 2060 W 2x 2460 W 2x 4225 W 4x 890 W 4x 1170 W - 4x 2080 W -
@ 4Ω 2x 610 W 2x 880 W 2x 1240 W 2x 1600 W 2x 2600 W 4x 580 W 4x 820 W 4x 1230 W 4x 1280 W 4x 2110 W
Frequency Response
Power Bandwidth ±0.25dB 20Hz-20kHz
Phase Response
@ 1 watt 20Hz-20kHz ±15 deg
Total Harmonic Distortion
20Hz-20kHz <0.05%
Intermodulation Distortion
SMPTE <0.05%
Damping Factor
20-500Hz @8Ω >500
Crosstalk
20Hz-1kHz>75 dB
Voltage Gain 26/32/38 dB
Sensitivity
Rated Power @ 8Ω (V) 2.6/1.3/0.6 3.0/1.5/0.8 3.6/1.8/0.9 4.0/2.0/1.0 5.0/2.5/1.3 2.6/1.3/0.6 3.0/1.5/0.8 3.7/1.9/0.9 3.5/1.8/0.9 5.0/2.5/1.3
Signal-to-Noise Ratio
20Hz-20kHz 112 dB 113 dB 115 dB 116 dB 118dB 112dB 113dB 116dB 116dB 118dB
Required AC Mains
230 V - 50 Hz (idle) 0.5 A 0.5 A 0.5 A 0.5 A 0.5 A 0.5 A 0.5 A 0.5 A 0.5 A 0.5 A
@ 4Ω (1/8 rated power) 4 A 4.8 A 6.2 A 7.5 A 10.5A 6 A 7.5 A 11A 10.5A 15A
Dimensions
W x H x D (mm) 483x89x310
W x H x D (inches) 19x3.5x12.2
Weight
Net (Kg- Lbs) 8-17.6 8-17.6 8.5-18.7 8.5-18.7 8.6-18.9 8.5-18.7 8.5-18.7 8.5-18.7 8.6-18.9 8.6-18.9
Protections
Soft-start, Turn-on Turn-off transients, Muting at turn-on, Over-heating, DC, RF, Short-circuit, Open or mismatched loads, Overloaded
power supply, ICL
™
, PMS
™
, SSP
™
