The S Series Power Amps is RAM
Audio's response to our discerning
clients' needs for a series of powerful,
compact, versatile and rugged ampli-
fiers characterised by no-compromise
electronic and mechanical specifica-
tions. The S Series range offers the
bonus of optional add-on modules that
extend its operational capability to
match any of today's market require-
ments.
The S Series incorporate unique abso-
lute protections as the PMS
or SSP
systems.
Instantaneous High Flow QuantaPulse
EVO Power Supply.
Ultra-compact and lightweight 2-U
high.
Laser cut aluminum front panels with
integrated carrying handles.
Neutrik
®
XLR input connectors, input
and signal link in 2 channel models.
Input Link switch: allow daisy-chaining
of the one channel input signal to
another adjacent channel.
Neutrik
®
Speakon
®
output connectors.
Detented sealed potentiometers for
easy recall of volume settings.
ICL, PMS, Hi-temp, Signal indicators
per channel.
Highly versatile with multiple configu-
ration possibilites and additional
module options.
Switchable ICL clip-limiters per chan-
nel.
Switchable and selectable (30 or 50
Hz) sub-sonic highpass filter per
channel.
Three-position gain selector (26, 32 or
38 dB).
Dual or Bridge mode operation.
Twin continuously variable, temperatu-
re controlled, back to front cooling
fans.
Oversized power components (high
SOA reserve specification).
1.2 Main Characteristics
1.1 Introduction
Die Endstufe S ist RAM Audios Antwort
auf die Nachfrage unserer Kunden nach
kompakten, leistungsstarken und gleich-
zeitig vielseitigen und belastbaren
Endstufen, die sich durch kompromiss-
lose Elektronik und mechanische
Ausführungen auszeichnen. Die S-
Reihe bietet außerdem die Möglichkeit
die Leistungsfähigkeit der Endstufen mit
optionalen Erweiterungsmodulen auszu-
bauen und so allen Anforderungen des
Marktes zu genügen.
Die S-Reihe verfügt über einzigartige
Schutzsysteme wie PMS
und SSP
.
Quantapulse-Stromversorgung mit
sofortigem Hochstrom.
Ultrakompakt und leichtgewichtig, 2U
hoch.
Lasergeschnittene Frontplatte mit inte-
grierten Tragegriffen.
Neutrik
®
XLR Eingangsstecker,
Eingangs- und Signallink bei 2-
Kanalmodellen.
Eingangsverbindungsschalter: ermö-
glicht die Verbindung des eingehen-
den Signales eines Kanales mit einem
anliegenden Kanal.
Neutrik
®
Speakon
®
Ausgangsstecker.
versiegelter Potentiometer mit 21
Stufen für den einfachen Abruf von
Volumeneinstellungen.
ICL-, PMS-, HI-Temp- und
Signalanzeiger pro Kanal.
Sehr vielseitig mit multiplen
Konfigurationsmöglichkeiten und
zusätzlichen Moduloptionen.
schaltbare Cliplimiter pro Kanal.
schaltbare und wählbare (30 oder
50Hz) Subssonic-Hochpassfilter pro
Kanal.
3-Punkt Gainselektor (26,32 oder
38dB).
Dual- oder Bridgemodusfunktion.
Zwei temperaturkontrollierte
Kühlungsventilatoren die von der
Rückseite der Endstufe nach vorne
blasen.
Überdimensionale Leistungskom-
ponenten (hohe SOA Reserve).
1.2 Allgemeine Eigenschaften
1.1 Einleitung
General Information
Les amplis de puissance de la Série S
sont en essence la réponse de RAM
Audio aux besoins de nos clients, face
à une demande croissante des métiers
du son pour des appareils puissants,
versatiles et résistants qui se caractéri-
sent principalement par des spécifica-
tions électroniques et mécaniques de
très haut niveau. La Série S offre en
plus optionnellement, des modules
additionnels qui accroissent leurs capa-
cités opérationnelles pour faire face aux
demandes du marché actuel, sans limi-
tes.
La Série S incorpore aussi des systè-
mes de protection absolue tels que: Le
PMS ou le SSP.
Grande capacité en courant instan-
tané QuantaPulse EVO.
Ultra-compact et léger, 2-U en hau-
teur.
Face avant en alu découpée au laser
avec poignées intégrées.
Connecteurs d’entrée type XLR
Neutrik
®
(doublés entrée-sortie pour
modèles de 2 canal).
Commutateur d'entrée "Link" qui per-
met la connection du signal d'un canal
à l'autre.
Neutrik
®
Speakon
®
de Sortie.
Potentiomètres crantés et étanches
pour un calage facile des niveaux.
Signalisation par LED de ICL, PMS,
Surchauffe et Signal.
Versatilité augmentée avec possibilité
de configuration multiple et option de
modules additionnels.
Limiteurs d'écrêtage ICL commutables
par canal.
Filtre passe-haut/subsonique commu-
table aux 30 ou aux 50 Hz au choix
par canal.
Trois niveaux de sensibilité au choix:
26, 32 ou 38dB, (réglage usine 32dB).
Conmutateur de mise en mode Bridge
ou Dual sur le panneau arrière.
Vitesse des ventilateurs asservie en
fonction de la température interne.
Modules de puissance munis de tran-
sistors avec SOA amplement dimen-
sionné.
1.2 Caractéristiques Générales
1.1 Introduction
Informations
Générales
Allgemeine
Anweisungen
3
