31
2.1 Renewal the millk nozzle
To increase the quantity of frothed milk,
change the standard emulsion nozzle
(indicated by a notch) removing the same
as indicated in the gure.
Install the large nozzle (identied by
2 notches) to increase the quantity of
whipped milk.
Note: ISTEAM nozzles are different to
those utilised for the TSC
2. DISPENSING STEAM WITH THE
ISTEAM SYSTEM
To use this function, press the specic
buttons on the button panel; it is automa-
tically stopped when the set temperature
is reached.
Safety Devices
No steam can be dispensed if the machi-
ne has not reached the operating pressu-
re or temperature at least once.
Steam dispensing is discontinued auto-
matically after 3 minutes if the set tempe-
rature has not yet been reached.
1. MAKING COFFEE
1.1 Number of Dispensers
The coffee maker is equipped with 4 coffee dispen-
sers with programmable dose and pre-brewing cycle
time.
1.2 Operating Cycle
When one of the coffee buttons is pressed for one of
the 4 dispensers, the following occurs:
- The dispensing solenoid valves are energized
and the pump motor starts for a time that can be
programmed between 0 and 5 sec
- The dispensing solenoid valves are de-energized
and the pump motor stops for a time that can be
programmed between 0 and 5 sec
- The dispensing solenoid valves are energized
and the pump motor starts until the programmed
impulses are reached, which start decreasing
during the rst phase.
