(all specs typical)
Computer interface USB 2.0 High Speed
USB Power Requirement 400 mA, 5.0 Volts
USB Audio Channels Six Record and Six Playback
External Power Supply 1060 mA, 7.5 Volts
Converters 24-bit / 44.1 kHz or 48 kHz sample rate
DAC Dynamic Range 104 dB, A-weighted
Line Thru Dynamic Range 101 dB, A-weighted
Phono Thru Dynamic Range 98 dB, A-weighted
THD+N 0.009% at 1 kHz at 2 Vrms
All Inputs Phono or Line Level Switchable
Line Input Unbalanced RCA
…...Gain Unity
…...Maximum Input / Output 3 Vrms
Phono Input Unbalanced RCA
……Sensitivity Adjustable 2.5 mV to 10 mV
RANE SL 3 FOR SERATO SCRATCH LIVE • OPERATOR’S MANUAL 1.8.4
32
