Rangemaster Infusion-110 - Technical Data; Connection; Dimensions; Ratings

31
10. Technical Data
INSTALLER: Please leave these instructions with the user.
DATA BADGE LOCATION: Cooker back, serial number repeater badge below the oven door opening.
COUNTRY OF DESTINATION: GB, IE.
Connection
Electric 230 / 400 V ~ 50 Hz 3N
Dimensions
Model Infusion 110 Induction
Overall height Min 905 mm Max 930 mm
Overall width 1100 mm
Overall depth 608 mm excluding handles, 650 mm including handles
Minimum space above hotplate
650 mm
See “Positioning the Cooker“.
Ratings
Max: 1.85 kW
Boost: 2.5 kW
Max: 1.85 kW
Boost: 3.0 kW
Max: 1.85 kW
Boost: 2.5 kW
Max: 1.15 kW
Boost: 2.0 kW
Max: 1.15 kW
Boost: 2.0 kW
Zone 1
Zone 2
Zone 3 Zone 5
Zone 4
Hotplate energy saving tips Oven energy saving tips
Use cookware with a at base. Cook meals together, if possible.
Use the correct size cookware. Keep the pre-heating time short.
Use cookware with a lid. Do not lengthen cooking time.
Minimise the amount of liquid or fat. Do not open the oven door during the cooking period.
When liquid starts boiling, reduce the setting. Do not forget to turn the appliance o at the end of cooking.
DocNo.103-0018 - Technical data - 90 IN - G5 GENERIC
