Rascal Balance 600 B - Illustration 1 - Take-Apart Components

Rascal 600B/700B Owner’s Manual
EMC Part: 19278100 Rev. 3 ◦ 06/29/2009
9
Rascal Balance Take-Apart Components:
1. Front Basket
2. Dash/Handlebar
3. Removable Seat
4. Rear Cover
5. Removable Batteries (under Rear Cover)
6. Take-Apart Three-wheel Front Section
7. Take-Apart Rear Section
8. Removable Drive Train
ILLUSTRATION 1 – Take-Apart Components
2. Handlebar and
Dash Controls
3. Seat
7. Rear Section
6. Front Section
8. Drive Train
Assembl
y
1. Front Basket
4. Rear Cover
5. Removable
Batteries
under Cover
