Removing Batteries
• Remove rear cover and undo the Velcro battery tie down strap.
• Unplug the connectors attached to each battery and lift each battery
up and out of the vehicle.
Re-Assembly Notes: Make sure that the Velcro straps are securely and
completely fastened.
Battery Battery
Battery
Connector
Battery
Connector
To Next Page
