Rascal 600B/700B Owner’s Manual
EMC Part: 19278100 Rev. 3 ◦ 06/29/2009
18
Adjusting Armrest Width
The two armrests of the seat can be adjusted to different widths. Follow
these instructions to adjust armrest width:
• Loosen corresponding knob behind the seat
• Adjust width by pulling armrest out from seat to desired position
• Retighten knob to secure armrest at selected width. Be sure to repeat
armrest adjustment on other side before riding.
ILLUSTRATION 4 – Armrest Width Adjustments
ILLUSTRATION 5A - Adjusting Armrest Angle
Move armrest
bracket to
adjust width
Loosen
Knobs
Lift Armrest
U
p
Adjust
An
g
le
