SYMBOLS USED IN THE MANUAL AND ON THE MACHINE
Symbols Description
B2167000
Read instruction manual.
FORBIDDEN!
Wear work gloves.
Wear work shoes.
B2167000
Wear safety earcaps.
99990758
Shock hazard.
999911770
Danger! Moving mechanical parts.
Caution: hanging loads.
Mandatory. Operations or jobs to
be performed compulsorily.
Danger! Be particularly careful.
Symbols Description
Move with fork lift truck or pallet
truck.
Lift from above.
B1541000
General danger.
Wear safety goggles.
Technical assistance necessary.
Do not perform any intervention.
B6419000
Mandrel rotation index plate.
B2166000
Risk of hands crushing.
Warning. Be particularly careful
(possible material damages).
Note. Indication and/or useful
information.
