Ravaglioli RAV540U User Manual

1919
0579-M090-0
RAV540U RAV540IU
CARATTERISTICHE TECNICHE
TECHNICAL SPECIFICATIONS
220V 60Hz 1Ph 220V 60Hz 3Ph 575V 60Hz 3Ph
Portata (lbs)
Capacity (lbs)
9000 (4082 kg)
Motore (kW)
Motor
(
kW
)
2,6 3 3
Tempo salita (“)
Lifting time (“)
75 37 37
Tempo discesa (“)
Descending time (“)
38 38 38
Peso (lbs)
Wei
g
ht
(
lbs
)
1874 (850 kg)
Emissione sonora dB (A)
Sound emission dB (A)
< 70
Min. bay size 15’ 6” x 22’ (4724 x 6706 mm)
Pressione aria (psi)
Air
p
ressure
(p
si
)
Min. 87 - Max. 145 (Min.6 - Max.10 Bar)
Pressione olio (psi)
Oil pressure (psi)
4496 (310 Bar)
6' 9 7/8"
(9 7/16")(4' 9 3/32")
(1' 3 11/32")
(6' 6 3/4")
(6' 9 3/32")
(5 5/16")
2' 13/32"2' 13/32" 2' 7 3/32"
(10")
3' 3 3/8"
(11 1/16")
6' 9 7/8"
(9 7/16")(4' 9 3/32")
(1' 3 11/32")
(6' 1 7/32")
(4' 4 5/32")
(6' 11 1/16")
(5 1/2")
2' 13/32"2' 13/32" 2' 7 3/32"3' 3 3/8"
(11 1/16")
(10")
(4' 4 5/32")
2' 2 9/16"2' 5 29/32"2' 2 9/16"
(19/32")(19/32")
(13/32")
(1 3/16")
(7 7/8") (2 3/4")

Ravaglioli RAV540U Specifications

General

Brand	Ravaglioli
Model	RAV540U
Category	Scissor Lifts
Language	English
