USER MANUAL
– RAVAS-3200
23
5.9 KG- LB switch
2
e1 e2 e3 F1 F2
NET
ID CODE PT TOTAL KG/LB
CLR
kg
KG/LB
1
5.8 Print out (option)
If the weighing system has been equipped with a printer, obtained and entered weighing
data can be printed. Date and time are only printed out with the option board installed.
In the printout a gross weight is indicated with the letters “B/G” and a net weight with the
letter “N”. A manually entered tare weight will also be printed and is indicated with the
letters “PT”. The total weight is shown with the letters “TOT”.
Standard printout Standard printout
without code with code
CODE 12345
B/G 1234.5 kg. B/G 1234.5 kg.
T 34.5 kg. T 34.5 kg.
N 1200.0 kg. N 1200.0 kg.
*1 *1
Nr. 1 Nr. 1
10/07/03 17:45 10/07/03 17:45
Total printout (always without code)
Tot. B/G 1234.5 kg.
Tot. T 34.5 kg.
Tot. N 1200.0 kg.
*1
Tot. Nr. 999
10/07/03 17:45
*1 Note: in case of a legal for trade unit, the alibi number will be printed here.
