2.Functional Diagram
1- Rearview mirror
2- Instrument panel
3- Front headlight
4- Front turn signal light
5- Front mudguard
6- Horn
7- Front suspension
8- Front reflector
9- Rear license plate light
10- Rear tail light
11- Rear turn signal light
12- Rear mudguard
13- Rear fork
14- Rear seat
15- Rear shock absorber
16- Motor
17- Front seat
18- Charging port
19- Ignition lock
20- Rear brake assembly
21- Chain
22- Tensioner wheel
23-Side support flameout switch
24-Side support
25-Peda
26-Battery
27-Controller
28-Front brake caliper
