Recommended Torque for Installation of Important Components
Number
Installation Position
Recommended Torque
1
Front wheel axle tightening
25-30N.m
2
Function switch tightening
3-5N.m
3
Rear wheel sprocket tightening
18-20N.m
4
Front and rear disc brake tightening
10-12N.m
5
Front and rear brake lever tightening
12-15N.m
6
Tension wheel tightening
18-20N.m
7
Tension arm tightening
20-22N.m
8
Footrest bracket tightening
30-35N.m
9
Motor fixing
20-22N.m
10
Rear fork tightening
30-35N.m
11
Rear shock absorber tightening
22-28N.m
12
Rear tailstock tightening
15-20N.m
13
Rear wheel axle tightening
60-70N.m
14
Handlebar tightening
7-9N.m
15
Steering column tightening (pre-tightening nut)
3-5N.m
16
Steering column compression nut tightening
40-45N.m
