Installation instructions for rear shock absorber mount:
Raise the rear tail frame to
facilitate the installation of the
rear shock absorber.
Align the front end of the shock absorber
with the mounting hole slot on the frame,
and tighten the securing bolt from the
left side to the bottom.
Align the shock absorber with the
mounting hole slot on the frame, and
thread the bolt through from the left
side to the bottom. Apply thread sealant
to the upper and lower damping nuts.
Use a 13# ring spanner to tighten the
left-side bolt and a 14# ring spanner to
tighten the right-side nut.
Warning: The original
shock absorber has undergone multiple
extreme tests. The manufacturer is not
responsible for any property damage or
personal injury resulting from
unauthorized modifications or damage
caused by force majeure. Apply thread
sealant to the shoc
k
absorber securing
nuts. Tighten the bolt and nut to a torque
of 22-28 N.m.
