Rawrr Mantis - Page 37

36
Controller Alarm Code List
Alarm Code
(Buzzer Beep)
Fault Name
Protective
Measures
Fault Diagnosis
1 (1 short)
Software
Overcurrent
Shutdown
1.Restart the key.
2.Replace the controller.
3.Replace the motor.
2 (2 short)
Motor Overspeed
Shutdown
1.Restart the key.
2.Replace the controller.
3.Replace the motor.
3 (3 short)
Battery
Overvoltage
Shutdown
1.Restart the key.
2.Check if the controller/air switch power
line is loose.
3.Replace the battery.
4 (4 short)
KEY Power
Abnormality
Shutdown
1. Restart the key.
2. 2.Replace the ignition lock.
3.Replace the battery.
5 (5 short)
12V Power
Supply
Abnormality
Shutdown
1. Replace the DC-DC converter.
6 (6 short)
5V Power Supply
Abnormality
Shutdown
1.Replace the throttle.
2.Replace the motor encoder.
3.Replace the controller.
7 (7 short)
Angle Sensor
Disconnected
Shutdown
1.eplace the throttle.
2.Replace the motor encoder.
3.Replace the controller.
8 (8 short)
Hardware
Overcurrent
Shutdown
1.Replace the shift lever.
2. Replace the controller.
3. Replace the motor.
9 (9 short)
Current Loop
Fault
Shutdown
1.Replace the controller.
10 (1 long)
Battery
Undervoltage
Derating
1.Charge the battery.
2.Replace the battery.
11 (1 long 1
short)
Controller
Overtemperature
Derating
1.Turn off the power and allow the controller
to cool down.
12 (1 long 2
short)
Motor
Overtemperature
Derating
1. Turn off the power and allow the motor to
cool down.
2. Replace the controller wiring harness.
3. Replace the motor wiring harness.
13 (1 long 3
short)
Motor
Temperature Too
High
Shutdown
1.Replace the controller.
14 (1 long 4
short)
Motor Signal
Interference
Shutdown
1.Replace the controller wiring harness.
2. Replace the motor
Electrical
schematic
diagram
Electrical
schematic
diagram
