Raychem QuickStat - Sensor Testing; Error Codes

Sensor Testing
Ifthesensorisdisconnectedorshort-circuited,theheatingsystemis
turned off. Test your sensor according to the following resistance table:
Error Codes
E0:Internalerror.Thethermostatmustbereplaced.
E2: External sensor short-circuited or disconnected.
Sensor
Temp (˚C) Temp (˚F) Value (ohm)
–10 –14 64000
0 32 38000
10 50 23300
20 68 14800
30 86 9700
QuickStat Installation & Operation Manual
6
© 2009 Tyco Thermal Controls LLC H57225 06/09
