User Guide of RFL-C3300W~RFL-C15000W
15
CAUTION: All the cables can only be connected when power
supply is off. Hot plug may damage the device.
CAUTION:
(1) Ensure that there are no fiber bends in radius less than 30cm
when the product is installed. Avoid excessive twisting and
tight bends during the robotic arm movements.
(2) Tight bends will damage the laser delivery system.
CAUTION:
(1) Keep the protective cap properly, prevent it from
contamination; Or the aperture will be contaminated when
capped.
(2) Make sure the aperture and the cavity of the processing head is
clean.
3.3 Cooling Requirements
Table 3 Cooling Requirements
Product number
C3000X
C4000X
C6000X
C8000X
C10000X
C12000X
C15000
Cooling capacity (kW)
≥10
≥12
≥20
≥24
≥30
≥36
≥45
Minimum flow (L/min)
＞
35
＞
45
＞
52
＞
64
＞
79
＞
94
＞
112
Maximum input
pressure (Bar)
7
Hose inner diameter
(mm)
Φ25
Φ32
Cooling system water temperature setting: 25 ± 0.5 °C.
Requirements on Cooling Water:
(1) Purified water should be used.
(2) In order to prevent the growth of mould that may lead to blockage, adding
alcohol solution to about 10% of the total volume is recommended.
(3) If ambient temperature is between -10
℃
and 0
℃
, we recommend to use 30%
alcohol(volume ratio), and replace it every 2 months.
