Raycus RFL-C8000X User Manual

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3300W~RFL-C15000W
27
MODULATION
36
MOD+
Brown
Input port of 24Vmodulation
signal
\
37
MOD-
White
\
PE
\
Protective Earth.Connecting
the protective earth with the
overall shield.
INTERLOCK
38
ITL_A
Brown
Remote protection. “ITL_A”
and “ITL_B” must be shorted
when the laser is powered on.
Failure to do this will cause the
alarm of laser.
\
39
ITL_B
White
RS-232
40
RX
Brown
“TX” of RS232
RS232 control
41
TX
White
“RX” of RS232
42
GND
Green
Groud of RS232
\
PE
\
Protective Earth.Connecting
the protective with overall
shield.
CAUTION：Please check the control voltage level and ensure
that the level is in accordance with the requirements. Over
voltage and voltage ripple may damage the product.
4.5 Operation Mode and Control
There are two different modes of operation-CW and modulation. In the CW
mode, the laser emits continuously, and you can set the output power by
percentage of output power. In the modulation mode, the laser emits in a waveform
of pulses. The pulse can be set by the frequency, duty cycle and power percentage.
Laser power can be set in two ways: by communicating commands through a
the serial port or by setting analog voltage through an external AD mode. At the
same time, there are two ways of laser optical control: communication command
through serial port or MODULATION signal control through the control interface.
4.6 Entering a Control Mode
The Figure 14 shows the process of entering a control mode.
