Raymarine C90w - NMEA 0183 Data Interface

3.5NMEA0183connection
ConnectionstoNMEA0183devicesaremadeusingthesupplied
Poweranddatacable.
White
IN
+ve
Green
IN
-ve
Yellow
OUT
+ve
OUT
+ve
OUT
-ve
IN
+ve
Brown
OUT
-ve
IN
-ve
Orange/
White
IN
+ve
Orange/
Green
IN
-ve
Orange/
Yellow
OUT
+ve
OUT
+ve
OUT
-ve
IN
+ve
Orange/
Brown
OUT
-ve
IN
-ve
NMEA
DEVICE
4800 baud
(transmit to
C-Series
only)
C-Series display
NMEA
DEVICE
4800/9600 baud
NMEA
DEVICE
4800/9600/38400 baud
Blue/
White
IN
+ve
Blue/
Green
IN
-ve
OUT
+ve
OUT
-ve
D11200-1
TheC-Serieshas3NMEAportsavailable:
•Port1:Inputandoutput,4800/9600baudrate.
•Port2:Inputandoutput,upto38400baudrate.
•Port3:Inputonly,4800baudrate.
NMEA0183cable
YoucanextendtheNMEA0183wireswithinthesuppliedpower
anddatacable.
Datacableextension
ThefollowingrestrictionsapplytoanyextensiontotheNMEA0183datawires.
Totallength(max)Cable
Upto5mHighqualitydatacable:
•2xtwistedpairwithoverallshield.
•50to75pF/mcapacitancecoreto
core.
32C-SeriesWidescreeninstallation
