.9Radarsettings
TheSettingsmenuprovidesaccesstotheRadarapp’sfeaturesandfunctions.Theoptionsavailable
intheSettingsmenuaredependentonthetypeofRadarscannerconnected.
Transmissiontab
SettingsDescriptionOptions
Scanner
AllowsyoutoselecttheR
adarscannerthatyou
wanttouse.
ListofavailableRadar
scanners.
DualrangeEnablesandDisablesdualrange .
•On
•Off
Channel
DetermineswhichchannelisshownintheR adar
app.
•Channel1
•Channel2
Antennasize
selection
OpenArrayR adarantennasizeselection.•4ft
•6ft
Timedtransmit
EnablesanddisablesTimedtransmit.
TimedtransmitconfiguresyourR
adartotransmit
atperiodicintervalstoconservepower.
•On
•Off
S tandbyDeterminesthelengthoftimetheRadarisin
StandbyforinTimetransmitmode.
•3min
•5min
•10min
•15min
T ransmit
DeterminestheamountofscanstheRadarwill
performwhentransmittinginTimetransmit
mode..
•10scans
•20scans
•30scans
View&Motiontab
SettingsDescriptionOptions
Orientation
Head-up
Thetopofthescreenalwayspointstowardsyour
vessel’
scurrentheadingandasyourheading
changestheRadarimagerotatesaccordingly.
InHead-upthemotionmodeisfixedtoRelative
motion.
North-up
Thetopofthescreenalwayspointstowards
northandasyourvessel’sheadingchangesthe
SHMrotatesaccordingly.
Course-up
InCourse-upthetopofthescreenalwayspoints
towardsyourdestinationandasyourheading
changestheSHMrotatesaccordingly.
•Head-up
•North-up
•Course-up
MotionmodeR elativemotion
Thepositionofyourvesselremainsfixed
onscreenandtheRadarimagemovesrelativeto
yourposition.
InRelativemotionmodeyoucanadjustyour
vessel’sonscreenpositionusingtheBoat
positionsetting.
Truemotion
StationaryRadartargetsremainfixedandmoving
targets,includingyourvessel,moveintrue
perspectivetoeachotherandtolandmass.As
yourvessel’spositionreachestheedgeofthe
•Relativemotion
•Truemotion
R adarapplication
