Raymarine RAY91 Errata Sheet

2.Frequencyband—Indicateswhichchannelfrequencyband
isinuse:
•USA—UnitedStatesofAmerica
•INT—International
•CAN—Canada
•WX—Weather
Note:SpeciallicensingisrequiredtoreceiveUSAand
Canadianchannelsets.
3.Statustext—Indicatesthecurrentradiomodee.g.:ATIS
Modeactive,WeatherAlert,Scanmodeetc.
4.New4digitchannels—Identifiesthefirst2digitswhenthe
radioissettooneofthenew4digitsimplexchannels.
5.Channel—Indicatesthecurrentchannelnumber,orthelast
2digitswhensettoa4digitchannel..
6.Location/TimeorLocation/COG/SOG—Dependingon
selectiondisplaysLocationcoordinatesandcurrenttimeor
LocationcoordinatesandcurrentCOGandSOG.
7.ChannelName—Indicatesthenameofthecurrentchannel.
8.Channeltype—Indicatesthetypeofchannel:
•s=Simplex—Simplexchannelstransmitandreceiveon
thesamefrequency.
•d=Duplex—Duplexchannelsuseseparatefrequenciesto
transmitandreceive.
9.Optionaltext—Providesextrauserguidance.
Statusbarsymbols
Thestatusbarisusedtodisplaysymbolsthatindicatetheradio’s
status.
SymbolNameDescription
Lowpower
Highpower
Indicatestheradio
transmittersisinlow
power(1watt)orhigh
power(25watt)mode
LocalIndicatestheradioisin
localreceptionmode,
whichdecreases
receiversensitivityin
hightrafficareasto
decreaseunwanted
reception
FoghornIndicatesthattheradio
isinFoghornmode.
TransmitIndicatestheradiois
currentlytransmitting
(e.g.thePTTbuttonis
beingpressed.)
SymbolNameDescription
ReceiveIndicatestheradiois
currentlyreceivinga
transmission
WeatherIndicatesthatthe
weatheralertsmodeis
activated.
DSCIndicatesthataDSC
callhasbeenreceived
GPSFixIndicatesiftheradio
hasaGPS/GNSSfix.
2
Ray90/91handbookerratasheet
