3-44 Raychart 320 Chartplotter
Figure 3-45: User Card Menu Screen
4. Press the SAVE WPT/RTE DATA TO CARD soft key; the warning and
Yes/No soft keys are displayed, see Figure 3-46.
Figure 3-46: Save Warning and Soft Keys
5. Press Yes to continue or No to abandon the operation and return to the
previous screen.
If the operation is successful, confirmation of the number of Routes
and Waypoints saved is displayed, see Figure 3-47.
USER CARD PRESENT
USER CARD MENU
D5527-1
LOAD WPT/
RTE DATA
FROM CARD
SAVE WPT/
RTE DATA
TO CARD
CHECK
CARD IN
USER SLOT
USER CARD PRESENT
WARNING
SAVING DATA TO THE USER
CARD WILL ERASE ALL EXISTING
WAYPOINT AND ROUTE DATA
ON THE CARD.
USER CARD MENU
D5538-1
YES
ARE YOU SURE ?
NO
81167_3.BOOK Page 44 Wednesday, November 21, 2001 2:12 PM
