3.1Installationchecklist
Installationincludesthefollowingactivities:
InstallationTask
1Planyoursystem.
2
Obtainallrequiredequipmentandtools.
3
Siteallequipment.
4Routeallcables.
5
Drillcableandmountingholes.
6Makeallconnectionsintoequipment.
7
Secureallequipmentinplace.
8Poweronandtestthesystem.
Schematicdiagram
Aschematicdiagramisanessentialpartofplanning
anyinstallation.Itisalsousefulforanyfuture
additionsormaintenanceofthesystem.The
diagramshouldinclude:
•Locationofallcomponents.
•Connectors,cabletypes,routesandlengths.
3.2Partssupplied
Thefollowingpartsaresuppliedwithyourproduct.
00
D13543-1
x3
x3
3m
3
1 2
4 5
6
1.Unit
2.Mountingseal
3.3m(9.84ft)SeaTalk
ng®
spurcable
4.Documentation
5.M4x40mmThreadedstudsx3(usedforsurface
mounting)
6.Fingernutsx3(usedforsurfacemounting)
Unpackyouproductcarefullytopreventdamageor
lossofparts,checktheboxcontentsagainstthelist
above.Retainthepackaginganddocumentationfor
futurereference.
