Technical Update
Issue Number: TU232
Page 1of 2
Date: 19
th
September 2005
Author: Bob Sims
Product Description: SmartPilot S1G, S2G, S3G
Serial Number(s): S1G – E12115 – 0850001
S2G – E12091 – 0850001
S3G – E12092 – 0850054
S3G IPS – E12177 - 0850003
Subject:
Introduction of new “Kionix” Rate Gyro module
Due to obsolescence of the earlier Murata type Gyro, a new Rate Gyro module (Kionix) has now been
introduced into production SmartPilot Course Computers. The list above indicates start serial numbers.
Improved high speed Performance:
The introduction of the Kionix Gyro will in some cases improve the high speed steering performance of
vessels fitted with the G version pilots.
Service Requirements - Course Computer back compatibility:
The application of the new Kionix gyro requires a modification to early Course Computer PCB’s by way
of a change of resistor values. (See diagrams).
Resistor & Gyro Consignment:
S1G:
Surface mount Resistor (R18) fitted:
Murata Gyro – R18 = 100k (0603)
Kionix Gyro – R18 = 113k (0603)
S2G / S3G:
Surface Mount Resistors (R145 & R147) fitted:
Murata Gyro – R145 & R147 = 10k (0805)
Kionix Gyro – R145 & R147 = 11.3k (0805)
