Chapter 1: Basic Operation 3
Displayed information
The Pilot Controller display screen provides the following information:
If the optional Rudder Reference Transducer is fitted to an SPX-5 Sport system, a
rudder position indicator on the display indicates the current position of the rudder, as
measured by the transducer. The rudder position indicator can be turned on or off
during display calibration (see the SmartPilot-X5 Sport Installation & Setup Guide for
details).
D10910-1
Distance units:
no units = kilometres
nm = nautical miles
SM = statute miles
Heading indicators
Variable text region (up to 9 characters/digits)
n
m
S
M
MAG
TRUE
Port and Starboard
direction-to-steer indicators
Rudder position indicator. Displayed only if
the optional rudder reference transducer is
fitted to the autopilot system. Otherwise,
this area is blank.
