Raypak XTherm Series User Manual

41
Table S: Setup/Adjust Menu
Item Application Range Description Default
TARGET H MODE 1, 2, 3 RSET <> SETP RSET = Outdoor Reset, SETP =Setpoint SETP
TANK SETP WH
OFF, 50°F to 150°F
Tank set point temperature
125°F
TANK DIFF WH
2°F to 10°F
Tank Differential temperature 5
POOL SETP P 50ºF to 104ºF, 106ºF Pool set point temperature 80ºF
POOL DIFF P 1ºF to 5ºF Pool Differential temperature 2ºF
POOL MAX P 110ºF to 120ºF Pool Maximum temperature 110ºF
MODE H MODE 1, 2, 3 1,2,3 Piping and application configuration. 1
SETPOINT H MODE 1, 2, 3
50°F to 220°F
Boiler target temperature while a heat demand is present for set-
point operation
180°F
OUT START H MODE 1, 2, 3
35°F to 85°F
Outdoor starting temperature - outdoor reset
70°F
OUT DESIGN H MODE 1, 2, 3
-60°F to 45°F
Outdoor design temperature - outdoor reset
10°F
Boil START H MODE 1, 2, 3
35°F to 150°F
Starting boiler target temperature when the outdoor temperature
is at outdoor start outdoor reset
70°F
Boil DESIGN H MODE 1, 2, 3
70°F to 200°F
Design boiler target temperature when the outdoor temperature is
at outdoor design outdoor reset
180°F
TARGET MAX H MODE 1, 2, 3
100°F to PIM value*
Maximum target system temperature
220°F
TARGET MIN H MODE 1, 2, 3
OFF, 50°F to 190°F
Minimum target system temperature
50°F
TARGET DIFF H MODE 1, 2, 3
2°F to 42°F
Differential for target system temperature
10°F
IND SENSOR H MODE 1, 2, 3 OFF <> ON Selects whether a DHW sensor is used for indirect DHW tank OFF
IND SETP H MODE 2, 3
OFF, 50°F to 180°F
Target Indirect DHW Temperature, requires IND SENSOR = ON
140°F
DHW DIFF H MODE 2, 3
2°F to 10°F
Differential for the target indirect DHW tank temperature, requires
IND SENSOR = ON
6°F
IND SUPPLY H MODE 2, 3
OFF, 50°F to PIM value*
Target boiler temperature for the DHW heat exchanger during
indirect DHW operation, requires IND SENSOR = OFF
180°F
DHW PRIORITY H MODE 2 OFF <> ON
Selects whether or not Indirect DHW priority is active during indi-
rect DHW operation
OFF
PRI OVR H MODE 2, 3 Au, 0:10hr to 2:00hr Sets the length of the indirect DHW priority override time 1:00hr
SYS PURGE All OFF, 0:20min to 20:00min Sets the length of the system pump post purge 20 seconds
MIX TYPE H / WH / P MIX
H (VALVE, PUMP, PLNT)
WH (1 <> 2)
Selects the type of control depending on pipe configuration for
CWP
H VALVE
WH 2
MIX TARGET H / WH / P MIX
50°F to 140°F
Inlet Target Temperature
120°F
MIX LOCK H / WH / P MIX OFF <> ON
The equipment will trigger a warning when “MIX Target” is not
reached within 7 minutes. MIX LOCK = ON; Alarm and lockout,
MIX LOCK = OFF; Alarm only
OFF
MIX TRIM H / WH / P MIX -5 to 5
This adjustment is for various types and sizes of units as well as
various actuator motor speeds and types supplied by Raypak
0
MIX SPEED H / WH / P MIX SLOW <> MED <> FAST This setting defines speed of response. MED
MIX INV H / WH / P MIX OFF <> ON
This option is related to the use of spring return actuators with a
proportional valve
OFF
WWSD H MODE 1, 2, 3
40°F to 100°F
The system warm weather shutdown temperature outdoor reset,
requires TARGET = RSET
70°F
UNITS All deg F <> deg C Show units using icons in display deg F
MODBUS All
OFF <> MNTR <>
TEMP <> RATE
ModBus Operating Mode: Off, Monitor, Temp Control, Rate
Control
MNTR
ADDRESS All 1 to 247 ModBus slave address 1
DATA TYPE All RTU <> ASCI Modbus data type RTU
BAUD RATE All
2400 <> 9600 <> 19K2 <>
57K6 <> 115K
19K2
PARITY All NONE <> EVEN <> ODD EVEN
* Maximum operator dial setting.
