42
Boiler Menu
The Boiler View displays various items regarding ignition, temperature monitoring, and modulation rates. As well
as software and hardware information
Table T: Boiler Menu
Item Application Description
BOILER 1 ALL Enables Boiler for operation
BOILER 2 CASCADE Enables Boiler for cascade operation
BOILER 3 CASCADE Enables Boiler for cascade operation
BOILER 4 CASCADE Enables Boiler for cascade operation
IGNITION ALL
IDLE=no CFH; PREP=pre-purge or inter-purge between trials for ignition; IGN=trial for
ignition; BURN=burner operating; POST=post purge; HARD=a hard lockout fault has
occurred requiring manual reset (Ignition Lockout or manual high limit); and SOFT=a
soft lockout fault has occurred which interrupts the heating cycle (any safety other than
ignition or manual high limit).
The CFH will resume after the soft lockout fault has been corrected and a 15 min.
waiting period has expired.
VENT WALL Not available Not Available
LIMIT TEMP ALL Current Outlet-Limit temperature
EMS Vdc ALL Current EMS signal in Volts DC
FIRE RATE ALL PIM firing rate
SPEEDX 1000 ALL Blower speed in revolutions per minute (rpm) x 1000
OUTLET MAX H Mode 1, 2, 3
Defines Max Outlet temperature offset above Target Setpoint (Press and hold up and
down arrows for 3 seconds to enable adjustment). see VERSA IC manual, catalog
5000.72.
OPERATOR ALL Operator Potentiometer setting on PIM
DIFF ALL Current auto differential – Fixed by PIM
Pump Post ALL Sets the length of the boiler pump purge
FLAME CUR ALL Flame current in micro-amps (µA)
MASS ALL Thermal mass recovery see VERSA IC manual, catalog 5000.72.
IDENTITY ALL Identifies the unit as boiler, water heater or pool heater
IGN
ALL
PIM
ID CARD ALL Identifies Raypak Identity Card
ERROR CODE ALL Current Error Code
