Raypak XTherm Series User Manual

43
Monitor Menu
The Monitor Menu records and displays critical Boiler information, such as, Cycle times, Run times, and
Maximum/Minimum temperature readings depending on the setup.
Table U: Monitor Menu
Item Application Description
RUN TIME Burner 1 All Burner run time (hours). Press UP/DOWN for 1 sec to clear.
Cycles Burner All Number of burner cycles. Press UP/DOWN for 1 sec to clear.
RUN TIME Boiler pump All Boiler pump run time (hours). Press UP/DOWN for 1 sec to clear.
RUN TIME System pump All System pump run time (hours). Press UP/DOWN for 1 sec to clear.
RUN TIME DHW pump H MODE 2, 3 DHW pump run time (hours). Press UP/DOWN for 1 sec to clear.
OUTLET HI All Records the highest boiler outlet temperature. Press UP/DOWN for 1 sec to clear.
OUTLET LO All Records the lowest boiler outlet temperature. Press UP/DOWN for 1 sec to clear.
INLET HI All Records the highest boiler inlet temperature. Press UP/DOWN for 1 sec to clear.
INLET LO All Records the lowest boiler outlet temperature. Press UP/DOWN for 1 sec to clear.
DELTA T All
Captures the highest Delta T Temperature recorded. Press UP &
DOWN buttons for 3 sec to clear this entry
OUTDOOR HI H MODE 1, 2, 3 Records the highest outdoor temperature. Press UP/DOWN for 1 sec to clear.
OUTDOOR LO H MODE 1, 2, 3 Records the lowest outdoor temperature. Press UP/DOWN for 1 sec to clear.
SYSTEM HI All Records the highest supply temperature. Press UP/DOWN for 1 sec to clear.
SYSTEM LO All Records the lowest supply temperature. Press UP/DOWN for 1 sec to clear.
IND HI H MODE 1, 2, 3 Records the highest Indirect supply temperature. Press UP/DOWN for 1 sec to clear.
IND LO H MODE 1, 2, 3 Records the lowest Indirect supply temperature. Press UP/DOWN for 1 sec to clear.
TANK HI WH Records the highest Tank temperature. Press UP/DOWN for 1 sec to clear.
TANK LO WH Records the lowest Tank temperature. Press UP/DOWN for 1 sec to clear.
POOL HI P Records the highest pool temperature. Press UP/DOWN for 1 sec to clear.
POOL LO P Records the lowest pool temperature. Press UP/DOWN for 1 sec to clear.
