Accessories
42 Rev. E2 04/2011 Marathon MR
If you cut the cable to shorten it, notice that both sets of twisted-pair wires have drain
wires inside their insulation. These drain wires (and the white wire that is not part of
the twisted pair) must be connected to the terminal labeled CLEAR. (Only necessary if
you cut the cable.) Refer to Section 2.3 for terminal block wiring diagram.
