Thermalert GP Series Operator’s Manual 15
2. When either S1 or S2 is displayed, press the or buttons to acti-
vate or deactivate the setpoint (a number “1” displays when the setpoint
is active, a number “0” displays when it’s inactive).
3. Press the button, and the display shows the current alarm tempera-
ture or value (Setpoint value). Use the up and down arrows to adjust the
alarm value.
4. Press the button again and a display similar to Figure 9 appears. If
you see a number “1,” it means the Normally Low setpoint will change
state when the target temperature or value exceeds the alarm value. If a
number “0” displays, the Normally Low setpoint will change state when
the target temperature or value is lower than the setpoint alarm value.
2.4.4 Setpoints 1 and 2
Setpoints are preset at the factory for the highest measurement value but are
deactivated by default. To adjust setpoints, complete the following:
1. In temperature/value display, press the button until a display similar
to Figure 8 appears. (Setpoint 1 shows as “S1” followed by a number 0,
showing that Setpoint 1 is Inactive, or a number 1, designating active.
O
N
L
C
F
Thermalert GP
Figure 8: Setpoint Display (Showing Setpoint 1 Active)
