3 Faultfinding
Edition:001 23 10000000015
Failure Error Code Possible Cause Remedy
Cable connection in
the gyro compass is
disturbed.
Call the Raytheon
Anschütz service for
repair.
Display shows the
error Pump Current
faulty.
EL18
Gyro compass com-
ponent is defective.
Call the Raytheon
Anschütz service for
repair.
Display shows the
error Temperature
Sensor faulty.
EL19
Gyro compass com-
ponent is defective.
Call the Raytheon
Anschütz service for
repair.
Display shows the
error Heating Sys-
tem faulty.
EL20
Gyro compass com-
ponent is defective.
Call the Raytheon
Anschütz service for
repair.
Software is corrupt-
ed.
Call the Raytheon
Anschütz service for
software update.
Display shows the
error Watch-Dog
Counter.
EL21
Gyro compass com-
ponent is defective.
Call the Raytheon
Anschütz service for
repair.
Cable connection is
disturbed.
Check the cable con-
nection to the gyro
compass.
Display shows the
error Power-On
Counter, if no normal
switch on / off was
performed..
EL22
Gyro compass com-
ponent is defective.
Call the Raytheon
Anschütz service for
repair.
24 V DC voltage
supply is disturbed.
Check the stability of
the 24 V DC voltage
supply.
Display shows
the error Off-State
Counter.
EL23
Gyro compass com-
ponent is defective.
Call the Raytheon
Anschütz service for
repair.
Cautions
Display shows the
caution Fan faulty.
CL01 Fan is defective.
Call the Raytheon
Anschütz service for
repair.
Display shows the
caution Heater
faulty.
CL02 Heater is defective.
Call the Raytheon
Anschütz service for
repair.
Display shows the
caution Support liq-
uid > 60 °C.
CL03
Air flow to the gy-
ro compass is dis-
turbed.
Check the air flow to
the gyro compass. If
required, establish
an open access to
the fan of the gyro
compass.
