Raytheon Anschütz Standard 22 NX User Manual

Gyro Compass Standard 22 NX
3 Faultfinding
10000000015 24 Edition:001
Failure Error Code Possible Cause Remedy
Gyro compass com-
ponent is defective.
Call the Raytheon
Anschütz service for
repair.
Support liquid level
is too low.
Call the Raytheon
Anschütz service for
repair.
Display shows the
caution Support liq-
uid too low.
CL04
Gyro compass com-
ponent is defective.
Call the Raytheon
Anschütz service for
repair.
24 V DC voltage
supply is disturbed.
Check the stability of
the 24 V DC voltage
supply.
Display shows the
caution Voltage cut-
off counter.
CL05
Gyro compass com-
ponent is defective.
Call the Raytheon
Anschütz service for
repair.
Other Disturbances
Gyro compass is out
of operation.
24 V DC voltage
supply is disturbed.
Check the availabili-
ty and connection of
the 24 V DC voltage
supply. If required,
switch on the power
supply.
A hose of support
liquid at the pump is
disconnected.
Call the Raytheon
Anschütz service for
repair.
Gyro compass has a
leakage.
Outer sphere is de-
fective.
Call the Raytheon
Anschütz service for
repair.
Cable connection is
disturbed.
Check the availabil-
ity and connection
of the position and
speed data source.
Position and speed
data input is not
available.
Position and speed
sources are defec-
tive or not available
Correct the speed
error manually, see
chapter 2.6.1.
