Raytheon Beech Baron E55 - Page 104

Ray~heon
AiKraft
Company
BARON
55
AND
58
SHOP
MANUAL
In
an
injection-type
system,
most
fuel
malfunctions
can
be
attributed
to
contaminated
fuel;
therefore,
the
wheel-well-mounted
strainers,
finger
strainers
and
sump
strainers
should be
inspected
and
cleaned
regularly.
The
frequency
of
inspection
and
cleaning
will
depend
upon
the service
conditions,
fuel
handling
equipment,
cleanliness
and local
sand and dust
conditions.
NOTE:
If
Goodyear
fuel
cells,
manufactured
after
1961
(Construction
No.
ETC-39
BTC-54A
and
ETC-67)
are
installed,
no
preservation
procedures
are
necessary
when
the
cell
is
to
be
empty
for
an
Indefinite
pen~d
of
time. The fuel
cells should
not
be
open
to
the
atmosphere
except
for
the
normal
vent
lines
in
the
airplane.
Goodyear
fuel
cells
manufactured
prior
to
1961 and
Uniroyal
fuel cells
must
be
filled
every
10
days
or
the
walls
must
be
coated with
a
thin
coat
of
light
engine
oil.
HEATER
FUEL
PUMP
After
every
100
hours of
airplane
operation,
remove
the
heater fuel
pump
strainer
by
turning
the
base of
the
pump
counterclockwise. Wash
the strainer
in clean
solvent
(15,
Chart
3)
and
blow
dry
with
compressed
air.
1
HEATER
FUEL
FILTER
NOTE:
Airplanes
TC-1406
and
After;
TE-847
and
After;
and
TH-176
and
After
do
not
have
the
heater
fuel filter
installed.
A
fuel
filter
is
installed in
the
nose
wheel
well
next to
the heater
fuel
pump
and filters
foreign
matter
from
the
fuel.
The
strainer is
equipped
with
a
snap-type
drain
and should
be
drained
daily
during
cold
weather
to
remove
accumulated
moisture
which,
if
allowed
to
freeze,
could
cause
heater
malfunction.
MAIN
FUEL STRAINER
SCREENS
Inspect
and
clean the
screens
each
100 hours
or
more
frequently
depending
on
the
service
conditions
and
when
operating
in
localities
where there is
an
excessive
amount
of
dust
or
sand
in
the
air.
INSPECTION
PROCEDUF)E
a.
Place
the fuel
selector
to
the
OFF
position.
b. Drain
the
fuel
strainers.
c.
Remove
the
safety
wire and
strainer
bolt.
d. Remove
the
screen
and
inspect
for
contaminants.
e.
Cleanthescreen
andblowdrywithdryair.
f.
Replace
the
gasket
and install
the
screen.
g.
Tighten
the
strainer
bolt and
install
safety
wire.
h.
Place the fuel
selector
to
the
ON
position.
i.
Place the mixture
control
to
the
OFF
position.
j.
Turn
the
boost
pump
ON
to
pressurize
the fuel
system.
Check for
leaks
at
the fuel
strainer.
k.
Turn the boost
pump
OFF.
ena
SECTION
2Pegs
19
