NOSE GEAR
CLEANING,
REPLACEMENT
PARTS
AND
REPAIRS
I
CLEANING
a.
Clean
all
parts
with
solvent
(15,
Consumable
Materials
Chart,
Section
2).
Remove all
excess
solvent
and
wipe
dry
after
cleaning.
b. Immerse
all
internal
parts
in clean
hydraulic
fluid
(13,
Consumable
Materials
Chart,
Section
2)
prior
to
assembly.
REPLACEMENT
PARTS
a.
Inspect
all
parts
and
assemblies
for
damage
or
excessive
wear.
The
following
conditions
are
cause
for
rejection:
Wear which
is
greater
than
the allowable
wear
tolerances.
Refer to
Chart
3.
Damage
which
cannot
be
corrected
or
repaired.
Screws
that
are
severely
damaged
or
have
stripped,
severely
worn
or
scored threads.
Parts that
are
cracked,
chipped
or
broken.
Parts that
have
corrosion
or
other
defects that
cannot
be
repaired.
b.
Replace
the
following
parts
when
nose
gear
is overhauled
(Ref.
Figure
11):
Adapter
(32)
Bushing
(12)
Cotter
Pins
Felt Pad
(24)
Piston
Ring
(7)
O-Rings (5,
38)
Safety
Wire
Scraper
(31)
Snap
Rings
(4,
33)
c.
Replace
the
following
parts
on
condition when
nose
gear
is
overhauled:
Bearings
(8,
22)
Bushings
(18,
28,
35,
45)
Grease
Fittings
Placards
Valve
Core
(1)
