g.
Remove
the
air
conditioning
hoses
and
ducts
from
the
evaporator
blower
module.
h.
Remove
the
evaporator
blower
attaching
bolts
and
remove
the
evaporator
blower module.
FORWARD
EVAPORA TOR BLOWER
MODULE INSTALLA
nON
I
a.
Place
the
forward
evaporator
blower
module in
position
and
secure
with
attaching
bolts
(refer
to
Figure
8).
b.
Remove
tags
from
the electrical
wiring
and
connect the wires
to
the
evaporator
blower
module.
I
c.
Connect
the
air
conditioning
system
hoses
and
duct
to
the
evaporator
blower
module.
d.
Place
the
metal
guard
in
position
around the
evaporator
module and
install
the
screws.
I
e.
Charge
the
air
conditioning
system.
Refer to
the
CHARGING
THE
AIR CONDITIONING
SYSTEM
procedure
inSection
2.
f.
Install
the
blanket
on
the
floor.
g.
Close the
baggage
compartment
door.
FORWARD
EVAPORA
TOR
BLOWER
MOTOR
REMOVAL
I
a.
Gain
access
to
the
forward
evaporator
blower
motor
through
the forward
baggage
compartment
(refer
toFigure
8).
b.
The
module
is located
to
the
rear
left
side
of
the
forward
baggage compartment.
c.
Remove
the blanket
from
the
floor.
d.
Remove
the
screws
from
the
metal
guard
around the
evaporator
module and
remove
the
guard
from
the
airplane.
e.
Tag
and
remove
the
electrical
wiring
from
the
evaporator
blower
motor.
f.
Remove
the
screws
from the
fan
closure.
g.
Remove
the
motor
and
fan
from the
evaporator.
FORWARD
EVAPORA TOR
BLOWER
MOTOR
INSTALLA
TION
I
a.
Place
the
motor
and
fan
in
position
on
the
evaporator
(refer
to
Figure
8).
b.
Install
the
screws
holding
the
fan
and
motor
in
place.
c.
Remove
the
tag
and
install
the
electrical wires
on
the
motor.
d. Place the
metal
guard
in
position
around the
evaporator
module
and install the
screws.
e.
Install
the
blanket
on
the
floor.
f. Close the
baggage
compartment
door.
