BARON
55
AND 58
SHOP
MANUAL
Chart
15
AVIONIC
EQUIPMENT
ELECTRICAL
UTILIZATION
MODEL
58
(TH-680
thru
TH-972)
Amperes
Equipment
Part
Number
Per
Unit
ADF
21A
2.80
ADF
218
2.10
ADF
System
ADF-T-12D
0.75
Audio
Amplifier
1028
0.50
Automatic
Flight
Control
FCS-810FD/AP
5.00
Encoding
Altimeter
3252013-0101
0.23
Glidescope/Marker
Recvr
GM-247A
0.30
Marker
Receiver
204A
0.16
Nav
System
RN-242A
0.66
Power
Supply
PS-243A
5.50
Transponder
TRR-660
1.30
VHF
Comm
Transceiver
RT-241A
0.80
VHF
Comm
Transceiver
RT-241A
4.56
VOR/ILS
Indicator
IN-245A
0.30
VOR/IOC
Indicator
IN-244A
0.06
Radar
Altimeter
TRN-71
1.30
ADF
System
DF-206
1.20
Amplifier
356C-4
0.19
Comm
Transceiver
VHF-20
0.60
Comm
Transceiver
VHF-20
5.00
DME
System
DME40
1.42
Glideslope
Receiver
517-5
0.25
Marker
Beacon
Receiver
512-6
0.45
Nav
System
VIR-30
0.80
Pictorial
Nav
System
PN-101
2.60
Radio
Altimeter
ALT-50
0.80
Transponder
TDR-90
1.90
VHF/NAV/Comm
Receiver
51R-7A
0.80
VHF/NAV/Comm
Receiver
51R-8A
1.00
VHF
Transceiver
618M-2
2.00
