BM111 SERIES 3KW Auto-Focusing Laser Cutting Heads User Manual
7 | 28
2.3 Cutting Head Shape
2.4 Cutting Head Configuration Diagram
2.4.1 Interface Type
Interface
Type
QBH-100mm
Fig 2.1 – Cutting head shape of BM111
Cable interface
QBH interface
Water-cooled
interface
Cutting gas
interface
Protective Lens
X-Y adjust
Nozzle-cooled
gas interface
