6
Attaching the Seat Cont.
Required Tools: 5 mm Allen wrench, Phillips screwdriver, 13 mm wrench.
ASSEMBLY AND SET-UP
3-2 Press firmly until click is heard.
6 Install seat/foot rest assembly.
4 Install the four (4) screws (included in bag
with the manual) using the Phillips screwdriver.
5 Remove four (4) foot rest bolts using the 5 mm
Allen wrench.
8 Install two (2) seat flat washers and nuts loosely using the 13 mm wrench.
7 Install four (4) foot pad bolts with washers loosely using the 5 mm Allen wrench.
To Next Page
