HEADLINE
3
BEFORE YOU BEGIN
3
WARNING: DO NOT USE
NON-RAZOR PARTS WITH YOUR
PRODUCT. The Ground Force Elite
has been built to certain Razor
design specifications. The original
equipment supplied at the time of
sale was selected on the basis of
its compatibility with the frame and
all other parts. Certain aftermarket
components may not be compatible
and will void the warranty.
NOTE: The lap belt arrangement
supplied is not intended for use in
larger, faster vehicles and is for
“play” use only. It is not an ASTM-
approved safety belt system and
is not intended to function as an
approved lap/seat restraining device.
Remove contents from box. Remove the separators that protect the components from damage during shipping.
Inspect the contents of the box for scratches in the paint, dents or kinked cables that may have occurred during
shipping. Because the Ground Force Elite was 95 percent assembled and packed at the factory, there should not be
any problems, even if the box has a few scars or dents.
MAKE SURE POWER SWITCH IS TURNED “OFF” BEFORE CONDUCTING ANY ASSEMBLY OR
MAINTENANCE PROCEDURES.
Estimated Assembly and Set-Up Time
Razor recommends assembly by an adult.
Allow up to 20 minutes for assembly, not including initial charge time.
Allow up to 12 hours for initial charge (see page 6 for charging information).
Charger
(Note: Charger design may
vary from one shown)
Required Tools, Hardware and Parts
4 mm and 6 mm Allen
Wrenches (included)
Allen Bolts (x4)
(included)
Washers (x4)
(included)
Seat Back Cushions
(x2) (included)
Plastic Bag Contents:
• Charger
• Allen Wrenches
• Bolts and Washers
• Seat Back Cushions
• Owner’s Manual
Product ID Locations:
(See locations to the left)
1. Underneath Frame
2. Side of Battery Box
3. Charger
4. UPC Side of Box (Not Shown)
3.
Charger Port
Steering Wheel
On/Off Switch
2.
1.
Speed Control/
Foot Throttle Pedal
Foot Brake Pedal
To Next Page
