18
SB 1918 (California) declaration:
YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR ACCIDENTS
INVOLVING THE USE OF THIS SCOOTER/ELECTRIC VEHICLE. TO DETERMINE IF
COVERAGE IS PROVIDED, YOU SHOULD CONTACT YOUR INSURANCE COMPANY
OR AGENT.
8. ILLUSTRATED PARTS BREAKDOWN
See Figure 14 (Specifications and parts list subject to change without notice)
ITEM# DESCRIPTION QUANTITY
01 Frame 1
02 Front wheel complete 2
03 Protector, Flexible steering 2
04 Spindle arm (right/left) 1
05 Steering column 2
06 Steering axle 1
07 Brake lever complete 1
08 Steering wheel 1
09 Thumb tab throttle 1
10 Cover, Steering 1
11 Seat 1
12 Battery cover 1
13 Reset button 1
14 Charger port w/ wires 1
15 On/ Off switch 1
16 Control module 1
17 Motor (24V / 200W) 1
18 Chain 1
19 Battery (2- 12V/ 7Ah) 1
20 Rear wheel complete 2
21 Cover, Rear axle 2
22 Rear axle 1
23 Bearing (6904RS) 2
24 Brake drum 1
25 Sprocket 1
26 Flag 1
