6
WARNING: Failing to properly adjust and tighten the screws, nuts and bolts that affix
the steering wheel and seat can cause you to lose control and crash.
Estimated assembly and adjustment time: allow up to 45 minutes, not including
initial charge time. Allow up to 8 hours for initial charge (see page 8 and 9 for
charging information)
3. Preparing for First-Time Use
3A. Un-box. Remove contents from box. Remove the foam separators that protect the
various components from damage during shipping. Inspect the contents of the box for
scratches in the paint, dents or kinked cables that may have occurred during shipping.
The Ground Force was 95 percent assembled and packed at the factory to prevent
shipping damage and there should not be any problems, even if the box has a few scars
or dents. But if there are, contact Razor USA, toll free, at (866) 467-2967 to resolve any
problems.
3B. Steering wheel. Remove the bolt and washers at the end of the steering axle as
shown in Figure 2a. Untangle the wires and orient as shown in Figure2b. Insert steering
axle into steering column as shown in Figures 2b and 2c.
Carefully turn the Ground Force on it’s side. We recommended that you have someone
hold the Ground Force up or, alternately, you can lean it against a wall for the installation
of the tie-rod to the steering axle.
WARNING: Flipping the Ground Force upside down is not recommended as it could
damage the control wires from the steering wheel.
• 5mm hex key wrenches.
• 10mm box wrench (spanner)
• Razor recommends assembly by an adult with experience in mechanics. Some tools may be
supplied, however we recommend the use of mechanic’s grade tools. Use the supplied tools only
as a last resort.
TOOLS REQUIRED FOR ASSEMBLY
