RC MI2S-600D - Installation Procedure; Position and Space Required

MI2S-600D/700D/800D 09
5.2 Installation Procedure
5.3 Position and Space Required
Please install the micro inverter and all DC connections under the PV module to avoid direct
sunlight, rain exposure, snow buildup, UV etc.The label side of the micro inverter should be up
and facing the PV module.
Leave a minimum of 1 0 cm of space around the micro inverter enclosure to ensure ventilation
and heat dissipation.
Do not connect the micro inverter to the grid until you have ensured that the installation is
complete as follows.
Make sure unused T-nodes and ends on the AC bus are sealed and that the AC feeder is powered as
long as the system is connected to the grid.
The top and bottom of the inverter should be left with at least 10cm of space to make it cooling.
Ensure that the support is in good connection with the micro inverter shell. The support must be
grounded for lightning protection.
Do not install the inverter in the position where the sun can directly shine on it.
Prepared and fixed the micro inverter to the PV support
CA UT IO N
WARNING
WARNING
WARNING
WARNING
