RC MI2S-600D - Indicator Light; Fault Clearing

MI2S-600D/700D/800D 18
Only qualified electrical engineers can connect the micro inverter system to the grid.
WARNING
Status of the inverter during operation are showed by Red and Green lights display.
7.1 Indicator light
Information
Classifying
Display Mode
Condition
Power On
Red green yellow flashes once in turn,
with an interval of 1 second.
Initialization completed
Runing
Green light flashing, interval of 1
second.
Producing power
Warning
Red light flashing, interval of 1 second.
Waiting for the grid
The inverter gets power from the DC side. If the DC voltage is within the working voltage range
of the inverter, the green LED flashes five times after the inverter is connected to the DC side,
CAUTION indicating that the initialization is normal.
Do not try to repair the micro inverter. If the fault cannot be rectified, please contact our
customer service. We will replace the products according to the situation.
Before maintaining the PV system, disconnect all circuit breakers in the bus box.
Do not disconnect the DC terminal when the inverter is working. It is best to cover the PV module
with an opaque object before disconnecting the DC side terminal.
WARNING
WARNING
WARNING
CA UT IO N
7.2 Fault Clearing
