Attaching/Removing the Belt Clip
Using a small screwdriver, align the belt clip’s screw
holes to the radio’s chassis. Attach by turning the
screws clockwise into the belt clip’s screw holes.
Remove by doing the reverse.
(See Figure 6)
Attaching/Removing the Antenna
1. With the radio turned off, set the antenna in its
receptacle and turn clockwise until it is screwed
down. (See Figure 5)
2. To remove the antenna, turn the radio off and
turn the antenna counterclockwise.
Figure 5
Figure 6
