Note: The frequency band of your BR200
TM
is on the radio label. If it is
not visible, identify the frequency band according to the color circle on
the antenna: white indicates UHF and red indicates VHF.
RCA BR200
TM
Overview
Push-to-Talk (PTT) Button
Programmable Button 1*
Programmable Button 2*
Programmable Button 3*
Channel Selector
On/Off/Volume Knob
LED Indicator
Microphone
Antenna
Belt Clip
Audio Accessory
Connector
1
2
3
4
5
6
7
8
9
10
11
* These buttons are programmable
by your RCA Communications
Systems Dealer upon request..
1
2
3
4
5
6
10
7
8
9
11
