RCA J22C760 - Rear Panel - J32 C750

Chapter 1
Chapter 1: Connections and Setup
13
Rear Panel - J32C750
1. AC IN
This TV operates on AC power.
2. HDMI/DVI IN
Connect to the HDMI jack on devices with an
HDMI output.
This input can also be used as a DVI connection
with separate analog audio inputs.
3. RGB IN (PC)
Connect to the video output jack on your PC.
4. COMPONENT IN (YPbPr)
Video/Audio inputs for Component.
5. AV1
Connects to your Audio/Video devices using a
composite (Yellow/Red/White) cable.
6. AUDIO IN (RGB/DVI)
Connect to the audio output jack on your PC.
7. ANTENNA/CABLE IN
Connect to your antenna or cable box for TV sig-
nal.
8. DIGITAL AUDIO OUT(COAXIAL)
Connect digital audio to various types of equip-
ment.
9. SERVICE
Used by clone device to learn settings in TV.
10.USB IN
USB device interface.
11.AV2
Connects to your Audio/Video devices using a
composite (Yellow/Red/White) cable.
HDMI/DVI
IN
RGB IN
(PC)
AUDIO IN
(RGB/DVI)
DIGITAL AUDIO
OUT(COAXIAL)
ANTENNA/
CABLE IN
3 6 7 8 92
VIDEO
YPbPr
LR
COMPONENT IN
AUDIO
AV IN
AUDIO
L
VIDEO
R
4 51
AC IN
SERVICE
10
11
USB IN
AV2
VIDEO L - AUDIO - R
Note
- Image shown may differ from your TV.
