RCA RDR9000 User Manual

Service Manual 6. UHF1 (400-470 MHz) Information
95
No.
Ref. No.
Print No.
Part No.
Description
1024
Q6014
T12K
ETNS04010000
NPN transistor
1025
Q7006
T8J
ETNS04010000
NPN transistor
1026
D5019
B4K
EDES06010002
ESD protection diode
1027
D2010
B5K
EDES06010003
ESD protection diode
1028
D5001
T1B
ESJ025000000
USB protection IC
1029
D5013
T6K
ESJ025000000
USB protection IC
1030
Q1004
T7C
ETNS04040000
NPN transistor
1031
D1005
T4C
EDXS03030000
Schottky barrier diode
1032
D2000
B2I
EDXS03030000
Schottky barrier diode
1033
D2003
B2I
EDXS03030000
Schottky barrier diode
1034
D2004
B2I
EDXS03030000
Schottky barrier diode
1035
D5015
B6B
EDXS03030000
Schottky barrier diode
1036
Q8006
T9H
EFAS02010000
PA MOSFET
1037
Q8005
T10H
EFAS02010001
PA MOSFET
1038
U1003
T6H
ESH016000004
Power management IC
1039
U1002
T5H
ESH016000003
Power management IC
1040
U1009
T1J
ESH016000000
Power management IC
1041
U1006
T6G
ESH016000002
Power management IC
1042
U1010
T4F
ESH016000002
Power management IC
1043
U1011
T2D
ESH016000002
Power management IC
1044
U1012
T12H
ESH016000002
Power management IC
1045
U1013
T12H
ESH016000002
Power management IC
1046
U2008
B2H
ESH016000002
Power management IC
1047
Q5015
B5B
EFPS03020000
P-MOSFET
1048
U8003
B8B
ESE028000000
Current sense amplifier
1049
U7000
T10K
ESD017000000
PLL IC
1050
D6002
B12H
ESZ017000000
Mixer IC
1051
U2006
T4J
ESR002000000
Logic IC
1052
U5000
B3D
ESR002000001
Logic IC
1053
U5001
B3H
ESR002000001
Logic IC
1054
U5002
B5I
ESR002000001
Logic IC
1055
U3003
B5H
ESN002000001
Baseband processor IC
1056
U4000
B7I
ESF002000000
D/A converter IC
1057
U2003
B2J
ESQ002000001
Reset IC
1058
U1000
T6E
ESH002000000
Power management IC
1059
U1001
T6G
ESH002000001
Power management IC
1060
U3010
T3G
ESP002000000
Analog switch IC
1061
U3000
T2G
ESP002000001
Switch IC
